SPECIFICATIONS:

Tractive (Push-Pull) Power Capacity, lbs (kg)…………..…. 1700 (771)

Tipping Capacity, lbs (kg)……………………….……………………........ 2,700 (1224)

Lift Height (to hinge pin)……………………………….……………....... 72” (183 cm)

Hydraulic Pump Capacity……………………………………………......... 12 GPM Gas / 14 GPM Diesel

Relief Pressure…………………………………………..……………….............. 3000 PSI

Drive System……………………………………………..………………............... Track

Self-Leveling Loaders Arms Standard……….………………….. Yes

Track Size………………………………………………….……………….................. 9” (23 cm)

Overall Height…………………………………………….….…………................ 87.8” (223 cm)

Body Height……………………………………………….…….………….............. 51.5” (130.8 cm)

Maximum Ground Speed…………………..…….……………........…….. 0-3.5 MPH

Length less bucket…………………………………….……….………........... 67” (170 cm)

Length w/bucket……………………………………..….…….……..........…... 86.4” (219 cm)

Wheel Base………………………………………………….…….………............... 31” (78.7 cm)

Reach at 45 degree Dump…………………………….…………........... 12.5” (31.8 cm)

Angle of Departure……………………………………….….…….…............ 26 Degrees

Width……………………………………………………..….….………................…... 42” (106.7 cm)

Ground Clearance………………………….……………..…………............... 6.5” (17 cm)

Start…………………………………………………..…………..………..................... 12 volt electric

Air cooled gas

Liquid cooled diesel
